Ultrasonic cavitation is a unique physical process when strong ultrasound is emitted in liquid. It is accompanied by many effects, mainly as follows: high temperature effect, discharge effect , luminescence effect and jet, impact, pressure effect, etc. This energy is sufficient to crush cells, degrade, reorganize and homogenize various inorganic substances or pulverize nanomaterials.
Brand:
METHERUltrasonic Homogenizer Model No.:
19~26KHzHomogenizer Timer Setting:
1 min~99hHomogenizer User Group:
10 GroupsSonicator Operating Mode:
Pulse.Timer.Continuous
| Model No. | Frequencies | Power | Capacity | Optional Probes | Standard Probe | Applications | Download |
| DL-300Y | 19~26KHz | 300W | 0.1~300ml |
Φ3(0.1~500ml) Φ6(50~300ml) Φ10(200~300ml) |
Φ3mm |
EP tube Microsample |
|
| DL-500Y | 19~26KHz | 500W | 0.1~600ml |
Φ3(0.1~50ml) Φ6(50~500ml) Φ8(300~500ml) |
Φ6mm |
Small processing Capacity |
|
| DL-1000Y | 19~26KHz | 1000W | 0.1~1200ml |
Φ(0.1~50ml) Φ(50~400ml) Φ8(500~1200ml) |
Φ10mm | Routine Laboratory | |
| DL-1500Y | 19~26KHz | 1500W | 0.1~1800ml |
Φ10(50~500ml) Φ16(50~1200ml) Φ18(1000~1800ml) |
Φ16mm | Routine Laboratory | |
| DL-1800Y | 19~26KHz | 1800W | 0.1~2200ml |
Φ10(50~500ml) Φ16(50~1200ml) Φ18(1000~2200ml) |
Φ18mm |
Large processing Capacity |
|
| DL-2000Y | 19~26KHz | 2000W | 0.1~3000ml |
Φ10(50~500ml) Φ16(50~1200ml) Φ18(1000~2200ml) Φ20(1000~3000ml) |
Φ20mm |
Large processing Capacity |
