The signal and power safety barriers are fixed in the explosion-proof control box, led out to the control panel through the explosion-proof stuffing box, the intrinsically safe circuit design of the display board is displayed.
Explosion-Proof Type A
The control panel, 1PT100 signal safety grid, one display panel signal safety grid, and one display panel power safety grid are arranged in the flamproof control box.
Explosion-Proof Type B
The shaded-pole fan and motor is arranged in the explosion-proof box, and explosion-proof packing and outgoing cables .
Casting Type
The compressor adopts casting type explosion-proof, also equipped with thermal fuse for temperature control.
Specifications
Model
MPC-5V416A
Shelf/drawer QTY
Wired shelf/5
Cooling system
Forced air
Defrost
Frost-free
Refrigerant
R290
Noise(db)
46
Ambient temperature (℃)
10~32℃
Temperature range(℃)
2~8℃
Compressor QTY
1
Sensor
NTC
Temperature controller
Microprocessor
Display
LED digital display
Voltage(V)
187~242C
Frequency(Hz)
50Hz/60Hz
Power Consumption(kWh/24h)
2.4
Power (W)
260W
Internal material
Coated steel
External material
Coated steel
Insulation
CFC-free PURF
High/low temperature
Y
Power failure
Y
Sensor error
Y
Door ajar
Y
Power failure backup system(alarm)
8 hours
Castor
Y
leveling feet
Y
Glycerine box/Qty
Y/1
Illumination
LED
Access port Qty/diameter
1/25mm
USB Interface
Optional
Remote alarm port
Y
Door type/Qty
Self-closing Solid/1
Data logger
Optional
AISI 304 interior
Optional
